MeyerPlowHelp.com is our newest site. Hopefully it will be an index of sorts for the info that is spread over all of our Meyer Plow web sites. It will also be a place where visitors can help each other with finding a fix for the particular problem they are having with their Meyer Plow.



Meyer E-58H Snow Plow Pump

Original Version of the Meyer E-58H in black. Previous versions were yellow. It has been replaced as the standard straight plow hydraulic unit by the E-72.

3-1-16 Meyer E-58H, E-68, E-88, E-72 C Valve Info

2-14-16 Meyer Plow Pistol Grip Controller Blinking - HELP!!!

10-6-15 Replacing an E-58H or E-72 with an E-47H, E-57H, or E-60H. Now you can have a spare!

8-6-14 Meyer Plow Wiring Diagrams, Wiring Identification Help (13 hours making this HUGE page!)

12-10-13 Meyer Plow Headlight Changeover Module Info

12-8-13 Meyer Plow Wiring Harnesses - Info and pin outs

12-7-13  Meyer 22690 Pistol Grip Controller Wiring Info

12-5-13 Meyer Nite Saber Headlight Adapters - Which one do you need?

Here is an exploded view of the E-58H with a list of part numbers.
You can click on the part numbers to order them at SmithBrothersPlowParts.com or just see the price.



The E-58H is the new standard unit made by Meyer Products. It replaces all previous standard units. It shares many parts with the E-47 and E-57 pumps. Although it is an H model, it also replaces all standard units as well. Meyer only produces H units now. Why? Beginning with the MD II (Meyer Diamond 2) mounting system, the H unit is what was on it. The MD II evolved into the EZ Plus mount, which is now standard. The EZ Classic (with the lift hoop) has been discontinued, and the EZ Classic was the only "current" (not anymore) mount that used a standard lift hydraulic unit. So now we have the E-58H going forward. It is backwards compatible though, with some additional parts and modifications:

Coupler Kit - The E-58H no longer has couplers (as of April 2008). Since the whole plow assembly comes off so easily, there is no reason to have couplers. To use an E-58H on a Custom Classic or EZ Classic mount, you need to order Part# 08206. You also need a pair of hose adapters.

Lift Arm - Current production 10514 (used on the Custom Classic and EZ Classic) Lift Arms have a new hole to use an E-58H already drilled in them. The 10514 Lift Arms are still used on the Drive Pro 6' 8" plows. To upgrade from an E-47, E-57, or E-60, you must drill a new hole as shown in the diagram below.
